Technical Specifications
Frameset
Frame
S-Works Aethos FACT 12r Carbon, Rider First Engineered™, Threaded BB, Electronic cable routing only, 12x142mm thru-axle, flat-mount disc
Suspension
Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Cockpit
Handlebars
S-Works Short & Shallow, 125mm Drop, 75mm Reach w/Di2 Hole
Stem
S-Works SL, alloy, titanium bolts, 6-degree rise
Tape
Supacaz Super Sticky Kush
Saddle
Body Geometry S-Works Power, carbon fiber rails, carbon fiber base
SeatPost
Roval Alpinist Carbon Seatpost
Seat Binder
Specialized Alloy, 30.0mm, titanium bolt
Brakes
Rear Brake
CAMPAGNOLO Super Record, Hydraulic Disc
Front Brake
CAMPAGNOLO Super Record, Hydraulic Disc
Drivetrain
Shift Levers
CAMPAGNOLO Super Record
Front Derailleur
CAMPAGNOLO Super Record, Braze-on
Rear Derailleur
CAMPAGNOLO Super Record, 12-speed
Cassette
CAMPAGNOLO Super Record, 12-speed, 10-29t
Crankset
CAMPAGNOLO Super Record, 12-speed
Chainrings
48/32T
Bottom Bracket
CAMPAGNOLO, Threaded
Chain
CAMPAGNOLO Super Record, 12-speed
Wheels & Tires
Front Wheel
CAMPAGNOLO Hyperon Ultra, 21mm internal carbon rim, 37mm depth, tubeless ready
Rear Wheel
CAMPAGNOLO Hyperon Ultra, 21mm internal carbon rim, 37mm depth, tubeless ready
Front Tire
S-works Turbo 2BR, 700x28mm
Rear Tire
S-works Turbo 2BR, 700x28mm
Inner Tubes
Turbo Ultralight, 48mm Presta valve
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
Geometry
49 | 52 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|
Crank Length | 170mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
Handlebar Width | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
Stem Length | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 300mm | 300mm | 360mm | 360mm | 360mm | 360mm |
Wheelbase | 973mm | 975mm | 978mm | 991mm | 1005mm | 1012mm |
Top Tube Length, Horizontal | 508mm | 531mm | 540mm | 562mm | 577mm | 595mm |
Bike Standover Height | 705mm | 728mm | 748mm | 769mm | 796mm | 824mm |
Seat Tube Length | 431mm | 462mm | 481mm | 504mm | 532mm | 567mm |
Seat Tube Angle | 75.5° | 74° | 74° | 73.5° | 73.5° | 73° |
Stack | 514mm | 527mm | 544mm | 565mm | 591mm | 612mm |
Reach | 375mm | 380mm | 384mm | 395mm | 402mm | 408mm |
Head Tube Length | 109mm | 120mm | 137mm | 157mm | 184mm | 204mm |
Head Tube Angle | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 74° |
BB Height | 266mm | 266mm | 268mm | 268mm | 268mm | 268mm |
BB Drop | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm |
Trail | 63mm | 58mm | 58mm | 55mm | 55mm | 52mm |
Fork Length, Full | 369mm | 369mm | 369mm | 369mm | 369mm | 369mm |
Fork Rake/Offset | 47mm | 47mm | 44mm | 44mm | 44mm | 44mm |
Front Center | 574mm | 577mm | 579mm | 591mm | 606mm | 613mm |
Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
