Technical Specifications
Frameset
Frame
Specialized P.1, A1 Premium Alloy, 20", Fully Butted Tubing, Tapered Head Tube, BSA 73mm BB Shell, 12x148TA Sliding Dropouts, Single Speed or Geared Compatible, 52mm CL, Internal cable routing, 30.9 Seat Tube, Dropper Post Compatible
Seat Binder
Quick Release, 34.9mm ID Clamp
Suspension
Fork
Specialized A1 Alloy, 20" Rigid, Tapered Alloy Steer Tube, 15x110TA, 372mm Axle to Crown
Cockpit
Saddle
Specialized P.series, Steel Rails
SeatPost
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
Handlebars
Mini Rise, Alloy Double Butted, 6-degree Backsweep, 600mm Width, 31.8mm , 19mm Bar End Diameter
Stem
3D-forged alloy, 31.8mm, 6-degree rise
Grips
Specialized Trail Grips, 19mm bar end diameter, lock-on
Brakes
Front Brake
Radius CX7, Mechanical Disc, 160mm Rotor
Rear Brake
Radius CX7, Mechanical Disc, 160mm Rotor
Drivetrain
Cassette
13T SS Cog
Chain
KMC Z1, 1/2x3/32", Single Speed
Crankset
Specialized P.series, 52mm CL, 115mm Length
Chainrings
30T
Bottom Bracket
BSA 73mm
Wheels & Tires
Front Hub
Alloy, 6-Bolt, 28H, 15x110 Boost
Rims
Specialized P.Series, 20", 32h, 26mm ID, Disc Brake Only
Rear Hub
Alloy, 6-Bolt, 28H, 12x148 Boost, 11-speed compatiable
Front Tire
Specialzied Kicker Sport, 20x2.1"
Rear Tire
Specialzied Kicker Sport, 20x2.1"
Spokes
Stainless, 14g
Inner Tubes
20" Inner Tube, SV
Accessories
Pedals
Specialized Platform Pedal
Weight
Weight
9.37kg (20 lb, 10.5 oz)
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 20" | |
|---|---|
| Crank Length | 115mm |
| Handlebar Width | 600mm |
| Stem Length | 35mm |
| Saddle Width | 110mm |
| Seatpost Length | 200mm |
| Stack | 429mm |
| Reach | 310mm |
| Head-Tube Length | 90mm |
| Head-Tube Angle | 68.5° |
| B-B Height | 259mm |
| B-B Drop | 5mm |
| Trail | 61mm |
| Fork Length (full) | 380mm |
| Fork Rake/Offset | 40mm |
| Front-Center | 520mm |
| Chain-Stay Length | 320mm |
| Wheelbase | 840mm |
| Top-Tube Length (horizontal) | 449mm |
| Bike Stand-Over Height | 561mm |
| Seat-Tube Length | 265mm |
| Seat-Tube Angle | 72° |
| Wheel Size | 20inch |
