Technical Specifications
FRAMESET
Frame
Hotwalk Fact 9r Carbon, 95mm Spacing
Fork
Hotwalk Fact 9r Carbon, 95mm Spacing
Seat Binder
Bolt-type, 27.4mm
COCKPIT
Stem
3D Forged Aluminum, 35mm length, 6 degree rise, 25.4mm clamp diameter
Handlebars
Carbon, 400mm width, 0mm rise, 5 degree backsweep, 15mm bar diameter
Grips
Specialized, slip-on, 19mm OD, 105mm length
Saddle
Hotwalk Carbon Integrated Saddle/Seatpost
SeatPost
Aluminum, 22.2mm
WHEELS
Rims
Fact Carbon 12" Rims, 16mm depth, 21mm internal width
Front Hub
Specialized sealed cartridge bearing hubs
Rear Hub
Specialized sealed cartridge bearing hubs
Front Tire
Rhythm Lite, Hotwalk Carbon lightweight casing, 12x2.0"
Rear Tire
Rhythm Lite, Hotwalk Carbon lightweight casing, 12x2.0"
* Specifications are subject to change without notice
Geometry
| unisex | |
|---|---|
| Stem Length | 35mm |
| Handlebar Width | 400mm |
| Seatpost Length | 200mm |
| Saddle Width | 118mm |
| Stack | 301mm |
| Reach | 185mm |
| Head-Tube Length | 70mm |
| Head-Tube Angle | 68° |
| B-B Height | 100mm |
| B-B Drop | 55mm |
| Trail | 46mm |
| Fork Length (full) | 200mm |
| Fork Rake/Offset | 15mm |
| Front-Center | 305mm |
| Chain-Stay Length | 255mm |
| Wheelbase | 549mm |
| Top-Tube Length (horizontal) | 277mm |
| Bike Stand-Over Height | 273mm |
| Seat-Tube Length | 175mm |
| Seat-Tube Angle | 73° |
