Technical Specifications
Frameset
Frame
FACT 11m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, SWAT downtube storage, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel
SWAT
SWAT internal downtube storage
Seat Binder
Specialized Alloy, 34.9, Steel bolt
Cockpit
Handlebars
Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
SeatPost
X-Fusion Manic, 30.9, 125/150/170 Travel, 0mm offset
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Saddle
Body Geometry Power Sport, steel rails
Grips
SRAM Slip on with Twist-Loc
Brakes
Front Brake
SRAM Level Bronze Stealth, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake
SRAM Level Bronze Stealth, 4-piston caliper, hydraulic disc, 160mm rotor
Drivetrain
Shift Levers
Sram AXS POD Controller
Rear Derailleur
SRAM S-1000 Eagle Transmission
Cassette
SRAM XS 1270 Transmission, 10-52t
Chain
SRAM GX Transmission
Crankset
SRAM S1000 Eagle, DUB, 165/170/175mm, 34T
Bottom Bracket
SRAM DUB Threaded Wide
Wheels & Tires
Rims
Specialized Alloy 29, 28mm internal width, tubeless
Front Hub
Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Spokes
DT Swiss Industry
Front Tire
Specialized Fast Trak, Control Casing, T7 Compound, 29x2.35
Rear Tire
Specialized Renegade, Control Casing, T5 Compound, 29x2.35
Inner Tubes
Standard 40mm PV 29x1.75-2.4
Product Details
Product ID
221499
Weight
Weight
11.89kg (26 lb, 3.4 oz)
Weight Size
MD
Suspension
Rear Shock
RockShox SIDLuxe Select+, Ride Dynamics developed 3 position, TwistLoc remote adjust, Solo Air, 190x45mm
Fork
RockShox SID Select, Ride Dynamics developed 3 position, TwistLoc remote adjust, Debon Air, 15x110mm, 44mm offset, 120mm Travel
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Crank Length | 165mm | 170mm | 170mm | 175mm | 175mm |
| Handlebar Width | 750mm | 750mm | 750mm | 750mm | 750mm |
| Stem Length | 60mm | 60mm | 60mm | 60mm | 60mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm |
| Seatpost Length | 100mm | 125mm | 150mm | 150mm | 170mm |
| Stack | 603mm | 597mm | 598mm | 610mm | 628mm |
| Reach (low) | 390mm | 420mm | 450mm | 475mm | 500mm |
| Head Tube Length | 92mm | 92mm | 95mm | 110mm | 130mm |
| Head Tube Angle (low) | 65.9° | 65.9° | 65.9° | 65.9° | 65.9° |
| Head Tube Angle (high) | 66.4° | 66.4° | 66.4° | 66.4° | 66.4° |
| BB Height (low) | 318mm | 324mm | 326mm | 328mm | 328mm |
| BB Height (high) | 323mm | 329mm | 331mm | 333mm | 333mm |
| BB Drop (low) | 52mm | 46mm | 44mm | 42mm | 42mm |
| Trail | 117mm | 117mm | 117mm | 117mm | 117mm |
| Fork Length, Full | 530mm | 530mm | 530mm | 530mm | 530mm |
| Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm | 44mm |
| Front Center | 687mm | 716mm | 747mm | 778mm | 811mm |
| Chainstay Length | 435mm | 435mm | 435mm | 435mm | 435mm |
| Wheelbase | 1117mm | 1147mm | 1179mm | 1210mm | 1243mm |
| Bike Standover Height | 748mm | 755mm | 760mm | 769mm | 774mm |
| Seat Tube Length | 370mm | 390mm | 410mm | 450mm | 500mm |
| Seat Tube Angle | 76.5° | 76° | 75.5° | 75.5° | 75.5° |
| Top Tube Length, Horizontal | 535mm | 569mm | 605mm | 633mm | 662mm |
