SPECIALIZED

Crux Expert

Crux Expert

91423-3061

MSRP 109,000.00
MSRP 109,000.00 MSRP 109,000.00
Sale Sold out
Vat Included
Color

1 in stock

Product Sold Out? Contact us and we will try to find it for you.

  • Visa
  • Mastercard

Read More

The Crux is the lightest gravel bike in the world, with the exceptional capability of massive tire clearance and performance gravel geometry. It’s not just the ultimate expression of gravel performance, it’s your one-way ticket to gravel enlightenment.

This Crux Expert comes spec'd with an intuitive and crisp-shifting SRAM Rival eTap AXS hydraulic disc groupset, incredibly tough Roval Terra C Disc wheels, and 2Bliss Ready, 700x38mm Pathfinder Pro tires that hookup over nasty terrain.

  • Lightest: 725g S-Works 12r and 825g 10r frames. We took the revolutionary breakthroughs that made Aethos the lightest bike ever and applied them to the Crux. The result? A gravel bike that climbs like a dream, floats over nightmarish terrain, and weighs less than a full bottle in your cage.
  • Capable: 47c/650b x 2.1” tire clearance. More clearance means more capability. With Diverge-level tire clearance, Crux takes you anywhere you can imagine, at full gas.
  • Responsive: Nimble, supple, and reactive. Responsive at the pedals. Supple in the saddle. With performance gravel geometry and race-influenced fit inspired by Crux’s iconic history in ‘cross.
View full details

Technical Specifications

Frameset

Frame

Crux FACT 10r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc

Suspension

Fork

S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc

Brakes

Front Brake

SRAM Rival eTap AXS, hydraulic disc

Rear Brake

SRAM Rival eTap AXS, hydraulic disc

Drivetrain

Chain

SRAM Rival 12-speed

Cassette

SRAM XPLR, XG-1251, 12-speed, 10-44t

Bottom Bracket

SRAM DUB BSA

Shift Levers

SRAM Rival eTap AXS

Crankset

SRAM Rival 1x

Rear Derailleur

SRAM Rival XPLR eTap AXS

Chainrings

40T

Wheels & tires

Front Wheel

Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 hub, 24h, DT Swiss Comp Race spokes

Rear Wheel

Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 hub, 24h, DT Swiss Comp Race spokes

Inner Tubes

700x28/38mm, 48mm Presta valve

Front Tire

Pathfinder Pro 2BR, Tan Sidewall, 700x38

Rear Tire

Pathfinder Pro 2BR, Tan Sidewall, 700x38

Cockpit

Saddle

Body Geometry Power Expert, titanium rails

SeatPost

Roval Terra Carbon Seat Post, 20mm Offset

Seat Binder

Specialized Alloy, 30mm

Handlebars

Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare

Stem

Specialized Pro SL, alloy, 4-bolt, 6-degree rise

Tape

Supacaz Super Sticky Kush

Weight

Weight Size

56

Weight

8.16kg (17 lb, 15.8 oz)

Geometry

 495254565861
Crank Length165170172.5172.5175175
Handlebar Width380400420420440440
Stem Length708090100110110
Saddle Width155155143143143143
Seatpost Length330330330380380380
Stack530547560578598621
Reach375382388397405415
Head Tube Length100115130147167190
Head Tube Angle70.571.2571.57272.2572.5
BB Height284284286286286286
BB Drop747472727272
Trail746967646260
Fork Length, Full401401401401401401
Fork Rake/Offset505050505050
Front Center594600608618630644
Chainstay Length425425425425425425
Wheelbase100810141023103310451059
Top Tube Length, Horizontal512539549568582599
Bike Standover Height749772794816841866
Seat Tube Length466496521546576606
Seat Tube Angle75.5747473.573.573.5
