Technical Specifications
Frameset
Frame
Tarmac SL7 FACT 9r Carbon, Rider First Engineered™, Win Tunnel Engineered, Clean Routing, Threaded BB, 12x142mm thru-axle, flat-mount disc
Suspension
Fork
FACT Carbon, 12x100mm thru-axle, flat-mount disc
Cockpit
Handlebars
Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
Saddle
Body Geometry Power Sport, steel rails
Stem
Tarmac integrated stem, 6-degree
Tape
Roubaix S-Wrap
SeatPost
2021 S-Works Tarmac Carbon seat post, FACT Carbon, 20mm offset
Seat Binder
Tarmac integrated wedge
Brakes
Rear Brake
Shimano 105, Hydraulic Disc
Front Brake
Shimano 105, Hydraulic Disc
Drivetrain
Shift Levers
Shimano 105, 12 speed Mechanical
Front Derailleur
Shimano 105, Braze-on
Rear Derailleur
Shimano 105, 12 speed Mechanical
Cassette
Shimano 105, 12-speed, 11-34t
Chain
Shimano SLX M7100, 12-speed w/ quick link
Crankset
Shimano 105, 12-speed
Chainrings
52/36T
Bottom Bracket
Shimano Threaded BSA BB
Wheels & Tires
Front Wheel
DT R470 Disc
Rear Wheel
DT R470 Disc
Front Tire
Turbo Pro, 700x26
Rear Tire
Turbo Pro, 700x26
Inner Tubes
Presta Valve Standard, 48mm valves
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
44 | 49 | 52 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|---|
Crank Length | 165mm | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
Handlebar Width | 360mm | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
Stem Length | 70mm | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
Saddle Width | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 300mm | 300mm | 300mm | 380mm | 380mm | 380mm | 380mm |
Head Tube Length | 93mm | 102mm | 113mm | 131mm | 151mm | 178mm | 198mm |
BB Height | 266mm | 266mm | 266mm | 268mm | 268mm | 268mm | 268mm |
Fork Rake/Offset | 47mm | 47mm | 47mm | 44mm | 44mm | 44mm | 44mm |
Head Tube Angle | 70.5° | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 74° |
BB Drop | 74mm | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm |
Fork Length, Full | 366mm | 366mm | 366mm | 366mm | 366mm | 366mm | 366mm |
Trail | 71mm | 63mm | 58mm | 58mm | 55mm | 55mm | 52mm |
Seat Tube Angle | 75.5° | 75.5° | 74° | 74° | 73.5° | 73.5° | 73° |
Front Center | 572mm | 574mm | 577mm | 579mm | 592mm | 606mm | 613mm |
Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
Bike Standover Height | 723mm | 735mm | 746mm | 768mm | 786mm | 808mm | 834mm |
Wheelbase | 970mm | 973mm | 975mm | 978mm | 991mm | 1006mm | 1013mm |
Seat Tube Length | 435mm | 447mm | 458mm | 475mm | 496mm | 517mm | 547mm |
Top Tube Length, Horizontal | 496mm | 509mm | 531mm | 541mm | 563mm | 577mm | 595mm |
Stack to Stem | 509mm | 522mm | 535mm | 552mm | 573mm | 599mm | 620mm |
Reach to Stem | 363mm | 372mm | 377mm | 381mm | 393mm | 400mm | 406mm |
Frame Stack | 491mm | 504mm | 517mm | 534mm | 555mm | 581mm | 602mm |
Frame Reach | 369mm | 378mm | 383mm | 387mm | 398mm | 405mm | 411mm |
