Technical Specifications
COCKPIT
SeatPost
2021 Tarmac Carbon seat post, FACT Carbon, 20mm offset
Saddle
Body Geometry Power Sport, steel rails
Handlebars
Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
Tape
Supacaz Super Sticky Kush
Stem
Tarmac integrated stem, 6-degree
Seat Binder
Tarmac integrated wedge
DRIVETRAIN
Chainrings
50/34T
Shift Levers
Shimano 105 Di2 R7170, 12-speed
Cassette
Shimano 105, 12-speed, 11-34t
Crankset
Shimano 105, 12-speed
Rear Derailleur
Shimano 105 Di2
Front Derailleur
Shimano 105 Di2, Braze-on
Chain
Shimano SLX M7100, 12-speed w/ quick link
Bottom Bracket
Shimano Threaded BSA BB
WHEELS & TIRES
Front Wheel
DT R470 Disc
Rear Wheel
DT R470 Disc
Inner Tubes
Presta Valve Standard, 48mm valves
Front Tire
Turbo Pro, 700x26
Rear Tire
Turbo Pro, 700x26
SUSPENSION
Fork
FACT Carbon, 12x100mm thru-axle, flat-mount disc
FRAMESET
Frame
Tarmac SL7 FACT 9r Carbon, Rider First Engineered™, Win Tunnel Engineered, Clean Routing, Threaded BB, 12x142mm thru-axle, flat-mount disc
BRAKES
Front Brake
Shimano 105, Hydraulic disc
Rear Brake
Shimano 105, Hydraulic disc
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
44 | 49 | 52 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|---|
Crank Length | 165mm | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
Handlebar Width | 360mm | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
Stem Length | 70mm | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
Saddle Width | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 300mm | 300mm | 300mm | 380mm | 380mm | 380mm | 380mm |
Frame Stack | 491mm | 504mm | 517mm | 534mm | 555mm | 581mm | 602mm |
Frame Reach | 369mm | 378mm | 383mm | 387mm | 398mm | 405mm | 411mm |
Stack to Stem | 509mm | 522mm | 535mm | 552mm | 573mm | 599mm | 620mm |
Reach to Stem | 363mm | 372mm | 377mm | 381mm | 393mm | 400mm | 406mm |
Head Tube Length | 93mm | 102mm | 113mm | 131mm | 151mm | 178mm | 198mm |
Head Tube Angle | 70.5° | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 74° |
BB Height | 266mm | 266mm | 266mm | 268mm | 268mm | 268mm | 268mm |
BB Drop | 74mm | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm |
Trail | 71mm | 63mm | 58mm | 58mm | 55mm | 55mm | 52mm |
Fork Length, Full | 366mm | 366mm | 366mm | 366mm | 366mm | 366mm | 366mm |
Fork Rake/Offset | 47mm | 47mm | 47mm | 44mm | 44mm | 44mm | 44mm |
Front Center | 572mm | 574mm | 577mm | 579mm | 592mm | 606mm | 613mm |
Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
Wheelbase | 970mm | 973mm | 975mm | 978mm | 991mm | 1006mm | 1013mm |
Top Tube Length, Horizontal | 496mm | 509mm | 531mm | 541mm | 563mm | 577mm | 595mm |
Bike Standover Height | 723mm | 735mm | 746mm | 768mm | 786mm | 808mm | 834mm |
Seat Tube Length | 435mm | 447mm | 458mm | 475mm | 496mm | 517mm | 547mm |
Seat Tube Angle | 75.5° | 75.5° | 74° | 74° | 73.5° | 73.5° |
