Technical Specifications
FRAMESET
FRAME
S-Works FACT 11r carbon, FACT IS construction, crosswind-optimized airfoils, 1-inch lower bearing, OSBB, Fit System, Integrated Nutrition and Hydration Fuelcells, disc brakes
SUSPENSION
FORK
S-Works FACT 11r carbon, integrated Fit System, flat-mount disc, 12x100mm thru-axle
COCKPIT
HANDLEBARS
Specialized Shiv Aerobar, carbon, variable stack adjust
TAPE
S-Wrap Roubaix w/ sticky gel
SADDLE
Sitero Pro, carbon rails
SEATPOST
Shiv Carbon, 0mm offset
BRAKES
FRONT BRAKE
Shimano Dura-Ace Di2 9170, hydraulic disc
REAR BRAKE
Shimano Dura-Ace Di2 9170, hydraulic disc
DRIVETRAIN
FRONT DERAILLEUR
Shimano Dura-Ace Di2 R9150, braze-on
REAR DERAILLEUR
Shimano Dura-Ace Di2 R9150, 11-speed
CASSETTE
Shimano Dura-Ace 9100, 11-speed, 11-28t
CRANKSET
S-Works Power Cranks, dual-sided power measurement, +/- 1.5% accuracy
CHAINRINGS
52/36T
BOTTOM BRACKET
OSBB, CeramicSpeed bearings
CHAIN
Shimano Dura-Ace, 11-speed
WHEELS & TIRES
FRONT WHEEL
Roval CLX 64 Disc rim, Roval AFD1, Center Lock™, CeramicSpeed bearings, 21h
REAR WHEEL
Roval CLX 64 Disc rim, Roval AFD2, Center Lock™, CeramicSpeed bearings, DT Swiss 240 internals, 11-speed, 12x142mm thru-axle, 24h
FRONT TIRE
Turbo Cotton, 320 TPI, 700x24mm
REAR TIRE
Turbo Cotton, 320 TPI, 700x24mm
INNER TUBES
Presta, 80mm valve
ACCESSORIES
PEDALS
Nylon, 105x78x28mm, loose ball w/ reflectors
* Specifications are subject to change without notice
Geometry
XS | S | M | L | |
---|---|---|---|---|
Crank Length | 165mm | 170mm | 172.5mm | 172.5mm |
Handlebar Width | 0000097791 | 0000097791 | 0000097791 | 0000097791 |
Stem Length | 0000095363 | 0000095363 | 0000095363 | 0000095363 |
Saddle Width | 0000085554 | 0000085554 | 0000085554 | 0000085554 |
Seatpost Length | 350mm | 350mm | 350mm | 350mm |
Stack | 484mm | 490mm | 514mm | 546mm |
Reach | 372mm | 386mm | 401mm | 421mm |
Head Tube Length | 70mm | 70mm | 94mm | 127mm |
Head Tube Angle | 70.25° | 72° | 72° | 72° |
BB Height | 265mm | 265mm | 265mm | 265mm |
BB Drop | 72mm | 72mm | 72mm | 72mm |
Trail | 68mm | 57mm | 62mm | 62mm |
Fork Length, Full | 385mm | 385mm | 385mm | 385mm |
Fork Rake/Offset | 50mm | 50mm | 45mm | 45mm |
Front Center | 578mm | 579mm | 596mm | 627mm |
Chainstay Length | 415mm | 415mm | 415mm | 415mm |
Wheelbase | 982mm | 983mm | 1001mm | 1031mm |
Top Tube Length, Horizontal | 484mm | 499mm | 520mm | 547mm |
Bike Standover Height | 752mm | 774mm | 798mm | 830mm |
Seat Tube Length | 490mm | 522mm | 547mm | 580mm |
Seat Tube Angle | 77° | 77° | 77° | 77° |
