Technical Specifications
| MODEL NO | RD-M986-SGS |
|---|---|
| SERIES | XTR M980 Series |
| Color | Series color |
| Average weight | 213 g |
| Remarks | *w/o bracket spec available |
|---|---|
| Top-normal spring type|SHIMANO SHADOW RD+ | ✔ |
| Mount|Direct attachment (conventional) | ✔ |
| Mount|Direct mount | X* |
| Max. front difference | 18T |
| Low sprocket|Max. | 36T |
| Low sprocket|Min. | 32T |
| Top sprocket|Max. | 11T |
| Top sprocket|Min. | 11T |
| Fluoric coated link bushings | 4 |
| Pulley|Guide pulley bearing | Sealed Bearing |
| Pulley|Tension pulley bearing | Sealed Bearing |
| Pulley|Teeth | 11T |
| Pulley|Sunken type pulley screw | ✔ |
| B-axle|Hollow axle | ✔ |
| B-axle 2|Hollow axle | ✔ |
