Technical Specifications
MODEL NO | FH-M8000 |
---|---|
SERIES | DEORE XT M8000 Series |
Color | Series color |
Average weight | 331 |
Color|1 Hub shell | Series color |
---|---|
Color|1 Quick release | Series color |
Brake type | CENTER LOCK disc brake |
Rear speeds | 11/10/9/8 |
O.L.D. (mm) | 135 |
Spoke hole|32H | ✔ |
External serration disc brake rotor lock ring|Without | ✔ |
Internal serration disc brake rotor lock ring|Without | ✔ |
Axle fixing method | Quick release |
Quick release skewer length (mm)|168 | ✔ |
Quick release skewer length (mm)|173 | ✔ |
Flange distance (mm) | 57.4 |
Offset (mm) | 6.9 |
P.C.D. left / right (mm) | 44/45 |
Flange diameter left / right (mm) | 52.8/53.8 |
Spline type|HG spline M (10/9/8-speed, MTB 11-speed) | ✔ |
Engagement type | Pawl ratchet |
Quick engagement | ✔ (more than 36 times/360 deg.) |
Seal|Hub | Labyrinth+Contact |
Seal|FREEHUB body | Contact |
Internal grease sleeve | ✔ |
