Technical Specifications
Frameset
Frame
S-Works FACT 12m Carbon, WCID suspension design, Progressive XC Race Geometry, Rider-First Engineered™, threaded BB, 12x148mm UDH compatible rear spacing, internal cable routing, 75mm of travel
SWAT
SWAT EMT Cage-Mount Tool
Seat Binder
Specialized Alloy 34.9, Titanium Bolt
Suspension
Rear Shock
RockShox-Specialized SIDLuxe WCID Ultimate, Ride Dynamics Developed, Independent negative spring, Rebound Adjust, 215x40mm
Fork
RockShox SID SL Ultimate, 3-position Raceday damper, Debon Air, 15x110mm, 44mm offset, 110mm Travel
Cockpit
Saddle
Body Geometry S-Works Power Mirror, carbon fiber rails, carbon fiber base, 143mm/155mm
SeatPost
Roval Control SL carbon seatpost, Two-bolt clamp, 0mm offset, 415/370mm x 30.9
Handlebars
Roval Control SL Integrated cockpit, 60mm/70mm X- 12 degree integrated stem, 8-degree backsweep, 1 degree upsweep, 760mm wide
Grips
SRAM Twist Lock
Brakes
Front Brake
SRAM Level Ultimate, 4-piston caliper, hydraulic disc, stealth, 180/160mm rotor
Rear Brake
SRAM Level Ultimate, 4-piston caliper, hydraulic disc, stealth, 160mm rotor
Drivetrain
Rear Derailleur
SRAM XX SL Eagle Transmission
Shift Levers
SRAM POD Ultimate AXS controller
Cassette
SRAM CS-1299 10-52t
Chain
SRAM XX Eagle
Crankset
Quarq XX SL power meter crankset, Carbon, 168 Q-Factor, DUB, 170/175mm, 34T
Chainrings
34t
Bottom Bracket
Ceramicspeed DUB BSA 73mm
Wheels & Tires
Rims
Control SL 29, 4mm FlatTop Bead Hooks, 29mm internal width, Tubeless Compatible, Tire Insert Compatible, 20h
Front Hub
Roval Control SL Team, DT Swiss Internals, Ceramic Bearings, 6-bolt, 15mm thru-axle, 110mm spacing, Torque caps, 20h
Rear Hub
Roval Control SL, DT Swiss 180 Internals, DT Swiss Ratchet EXP, Ceramic bearings, 12mm thru-axle, 148mm spacing, 20h
Spokes
Roval by VONOA Carbon Round Straightpull
FRONT TYRE
Specialized Fast Trak, S-Works Casing, T5/T7 Compound, 29x2.35
Rear Tire
Specialized Renegade, S-Works Casing, T5/T7 Compound, 29x2.35
Inner Tubes
Specialized Turbo Tube
Product Details
Product ID
221793
Weight
Weight
9.31kg (20 lb, 8.4 oz)
Weight Size
MD
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
S | M | L | XL | |
---|---|---|---|---|
Crank Length | 170mm | 170mm | 175mm | 175mm |
Handlebar Width | 760mm | 760mm | 760mm | 760mm |
Stem Length | 60mm | 70mm | 70mm | 70mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 370mm | 415mm | 415mm | 415mm |
Stack | 600mm | 600mm | 614mm | 628mm |
Reach | 415mm | 440mm | 465mm | 490mm |
Head Tube Length | 93mm | 95mm | 110mm | 125mm |
Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° |
BB Height | 313mm | 313mm | 313mm | 313mm |
BB Drop | 58mm | 57mm | 57mm | 57mm |
Trail | 113mm | 113mm | 113mm | 113mm |
Fork Length, Full | 516mm | 516mm | 516mm | 516mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
Front Center | 701mm | 726mm | 757mm | 788mm |
Chainstay Length | 430mm | 430mm | 430mm | 430mm |
Wheelbase | 1124mm | 1150mm | 1181mm | 1212mm |
Bike Standover Height | 761mm | 764mm | 774mm | 786mm |
Seat Tube Length | 395mm | 410mm | 450mm | 500mm |
Seat Tube Angle | 74.5° | 74.5° | 74.5° | 74.5° |
Top Tube Length, Horizontal | 581mm | 612mm | 641mm | 670mm |
