Technical Specifications
Frameset
Frame
Specialized FACT 11m, Progressive XC Geometry, Rider-First Engineered™, threaded BB, UDH, 12x148mm rear spacing, internal cable routing
SWAT
SWAT EMT Tool
Seat Binder
Specialized Alloy 34.9, Alloy Bolt
Suspension
Fork
Rockshox SID SL, Rush RL Damper, Debon Air, 15x110mm, 44mm offset, 100mm Travel
Cockpit
Saddle
Body Geometry Power Sport, steel rails
Handlebars
Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
SeatPost
Specialized Alloy, Single Bolt, 30.9mm
Grips
Specialized Trail Grips
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Brakes
Front Brake
SRAM Level Bronze 2-piston, Stealth, 180/160mm rotor
Rear Brake
SRAM Level Bronze 2-piston, Stealth, 160mm rotor
Drivetrain
Shift Levers
Sram AXS POD Controller
Chain
SRAM GX Transmission
Cassette
SRAM XS 1270 Transmission, 10-52t
Bottom Bracket
SRAM DUB Threaded Wide
Crankset
SRAM S1000 Eagle, DUB, 165/170/175mm, 34T
Rear Derailleur
SRAM S-1000 Eagle Transmission
Chainrings
34t
Wheels & Tires
Rear Hub
Specialized alloy, sealed cartridge bearings, 6-bolt, 12x148mm thru-axle, 28h
Spokes
DT Swiss Industry
Front Tire
Specialized Fast Trak, Control Casing, T7 Compound, 29x2.35
Rims
Specialized 29, 27mm inner width, 28h, tubeless ready
Rear Tire
Specialized Renegade, Control Casing, T5 Compound, 29x2.35
Inner Tubes
Standard 40mm PV 29x1.75-2.4
Front Hub
Specialized alloy, sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28h
Weight
Weight
10.37 kg (22 lb, 13.8 oz)
Weight Size
LG
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
XS | S | M | L | XL |
|---|---|---|---|---|
| Crank Length | 165 | 170 | 170 | 175 |
| Handlebar Width | 750 | 750 | 750 | 750 |
| Stem Length | 60 | 60 | 70 | 70 |
| Saddle Width | 155 | 155 | 143 | 143 |
| Seatpost Length | 350 | 350 | 400 | 400 |
| Stack | 594 | 608 | 608 | 622 |
| Reach | 385 | 405 | 430 | 455 |
| Head Tube Length | 95 | 95 | 95 | 110 |
| Head Tube Angle | 68.5 | 68.5 | 68.5 | 68.5 |
| BB Height | 309 | 309 | 309 | 309 |
| BB Drop | 63 | 63 | 63 | 63 |
| Trail | 101 | 101 | 101 | 101 |
| Fork Length, Full | 486 | 506 | 506 | 506 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 |
| Front Center | 643 | 670 | 695 | 725 |
| Chainstay Length | 430 | 430 | 430 | 430 |
| Wheelbase | 1064 | 1092 | 1117 | 1148 |
| Top Tube Length, Horizontal | 555 | 579 | 604 | 633 |
| Bike Standover Height | 732 | 762 | 792 | 816 |
| Seat Tube Length | 367 | 400 | 430 | 470 |
| Seat Tube Angle | 74 | 74 | 74 | 74 |
