Technical Specifications
Frameset
Frame: FACT 11m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, SWAT downtube storage, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel
Seat Binder: Specialized Alloy, 34.9, Steel bolt
SWAT: SWAT internal downtube storage
Suspension
Fork: RockShox SID ULTIMATE, Ride Dynamics developed 3 position, TwistLoc remote adjust, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Rear Shock: RockShox SIDLuxe ULTIMATE, Ride Dynamics developed 3 position, TwistLoc remote adjust, Solo Air, 190x45mm
Cockpit
SeatPost: Bike Yoke Divine SL, 30.9mm, SM: 100/ MD-XL: 125mm,
Saddle: Body Geometry Power Expert
Handlebars: S-Works Carbon XC Mini Rise, 6-degree upsweep, 8-degree backsweep, 10mm rise, 760mm, 31.8mm
Grips: SRAM Slip on with Twist-Loc
Stem: Specialized Pro SL, alloy, 4-bolt
Brakes
Rear Brake: SRAM Level Silver, 4-piston caliper, hydraulic disc, stealth, 160 rotor
Front Brake: SRAM Level Silver, 4-piston caliper, hydraulic disc, stealth, 180mm rotor
Drivetrain
Shift Levers: SRAM AXS POD Controller
Bottom Bracket: SRAM DUB Threaded Wide
Chain: SRAM X0 Eagle
Rear Derailleur: SRAM X0 Eagle Transmission
Crankset: SRAM X0 Eagle, Quarq Spindle power meter, DUB, 170/175mm
Cassette: SRAM XS 1295, 12 speed, 10-52
Chainrings: Alloy 34t
Wheels & Tires
Rims: Roval Control, Carbon offset design, 29mm internal width, 4mm hook width, Tubeless ready, 28h
Front Hub: DT Swiss 350, 6-bolt, 15mm Thru-axle, 110mm spacing, 28h straight -pull
Rear Hub: DT Swiss 350 straight-pull, 6-bolt, DT Swiss Ratchet, 12x148mm thru axle, XD freehub body, 28h straight-pull
Front Tire: Specialized Fast Trak, Control Casing, T7 Compound, 29x2.35
Rear Tire: Specialized Renegade, Control Casing, T5 Compound, 29x2.35
Spokes: DT Swiss Comp Race
Inner Tubes: Specialized Turbo Tube
Weight
Weight: 10.87kg (23 lb, 15.4 oz)
Weight Size: MD
Geometry
GEOMETRY
XS | S | M | L | XL | |
---|---|---|---|---|---|
Crank Length | 165mm | 170mm | 170mm | 175mm | 175mm |
Handlebar Width | 750mm | 750mm | 750mm | 750mm | 750mm |
Stem Length | 60mm | 60mm | 60mm | 60mm | 60mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 100mm | 125mm | 125mm | 150mm | 170mm |
Head Tube Angle (high) | 66.4° | 66.4° | 66.4° | 66.4° | 66.4° |
Stack | 603mm | 597mm | 598mm | 610mm | 628mm |
Trail | 117mm | 117mm | 117mm | 117mm | 117mm |
Chainstay Length | 435mm | 435mm | 435mm | 435mm | 435mm |
Seat Tube Angle | 76.5° | 76° | 75.5° | 75.5° | 75.5° |
BB Height (low) | 318mm | 324mm | 326mm | 328mm | 328mm |
Fork Length, Full | 530mm | 530mm | 530mm | 530mm | 530mm |
Reach (low) | 390mm | 420mm | 450mm | 475mm | 500mm |
Top Tube Length, Horizontal | 535mm | 569mm | 605mm | 633mm | 662mm |
Wheelbase | 1117mm | 1147mm | 1179mm | 1210mm | 1243mm |
BB Height (high) | 323mm | 329mm | 331mm | 333mm | 333mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm | 44mm |
Head Tube Length | 92mm | 92mm | 95mm | 110mm | 130mm |
Bike Standover Height | 748mm | 755mm | 760mm | 769mm | 774mm |
BB Drop (low) | 52mm | 46mm | 44mm | 42mm | 42mm |
Front Center | 687mm | 716mm | 747mm | 778mm | 811mm |
Head Tube Angle (low) | 65.9° | 65.9° | 65.9° | 65.9° | 65.9° |
Seat Tube Length | 370mm | 390mm | 410mm | 450mm | 500mm |
