Technical Specifications
Frameset
Frame
Specialized Diverge FACT 9r carbon, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc
Seat Binder
Specialized Alloy, 30.8mm
Suspension
Fork
Future Shock 2.0 w/ Smooth Boot, 12x100mm thru-axle, flat-mount disc
Cockpit
Handlebars
Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare
SeatPost
Roval Terra Carbon Seat Post, 20mm Offset
Stem
Future Stem, Comp
Tape
Supacaz Super Sticky Kush
Saddle
Body Geometry Power Sport, steel rails
Brakes
Rear Brake
SRAM Apex eTAP AXS, hydraulic disc
Front Brake
SRAM Apex eTAP AXS, hydraulic disc
Drivetrain
Rear Derailleur
SRAM X1 Eagle AXS
Shift Levers
SRAM Apex eTap AXS
Cassette
SRAM PG1210, 12-Speed, 11-50t
Chain
SRAM, NX Eagle, 12-speed
Crankset
SRAM Apex DUB Wide
Chainrings
40T
Bottom Bracket
SRAM DUB BSA
Wheels & Tires
Front Wheel
DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples
Rear Wheel
DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples
Front Tire
Pathfinder Pro 2BR, Tan sidewall, 700x42
Rear Tire
Pathfinder Pro 2BR, Tan sidewall, 700x42
Inner Tubes
700x28/38mm, 48mm Presta valve
Accessories
SWAT
Integrated SWAT door, internal storage system
Weight
Weight
9.99kg/22lbs, .4oz
Weight Size
56cm
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Crank Length | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Handlebar Width | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
| Stem Length | 60mm | 70mm | 80mm | 90mm | 100mm | 100mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
| Seatpost Length | 330mm | 330mm | 380mm | 380mm | 380mm | 380mm |
| Stack | 571mm | 577mm | 592mm | 610mm | 634mm | 659mm |
| Reach | 365mm | 374mm | 383mm | 392mm | 401mm | 410mm |
| Head Tube Length | 99mm | 104mm | 116mm | 133mm | 159mm | 185mm |
| Head Tube Angle | 70° | 70.5° | 71.25° | 71.75° | 71.75° | 71.75° |
| BB Height | 270mm | 270mm | 270mm | 270mm | 270mm | 270mm |
| BB Drop | 80mm | 80mm | 80mm | 80mm | 80mm | 80mm |
| Trail | 69mm | 66mm | 61mm | 57mm | 57mm | 57mm |
| Fork Length, Full | 389mm | 389mm | 389mm | 389mm | 389mm | 389mm |
| Fork Rake/Offset | 55mm | 55mm | 55mm | 55mm | 55mm | 55mm |
| Front Center | 607mm | 614mm | 620mm | 630mm | 647mm | 664mm |
| Chainstay Length | 425mm | 425mm | 425mm | 425mm | 425mm | 425mm |
| Wheelbase | 1019mm | 1026mm | 1032mm | 1042mm | 1059mm | 1076mm |
| Top Tube Length, Horizontal | 529mm | 542mm | 558mm | 573mm | 589mm | 605mm |
| Bike Standover Height | 700mm | 725mm | 754mm | 779mm | 805mm | 832mm |
| Seat Tube Length | 390mm | 430mm | 470mm | 500mm | 530mm | 560mm |
| Seat Tube Angle | 74° | 73.75° | 73.5° | 73.5° | 73.5° | 73.5° |
