Frameset

Frame

Crux 5 FACT 10r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout

Suspension

Fork

S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc

Brakes

Front Brake

SRAM RED E1, hydraulic disc

Rear Brake

SRAM RED E1, hydraulic disc

Drivetrain

Shift Levers

SRAM RED AXS E1, hydraulic disc

Rear Derailleur

SRAM RED AXS XPLR E1, 13-speed

Cassette

SRAM RED XPLR E1, 13-speed, 10-46t

Chain

SRAM RED E1 Flattop 12-speed

Crankset

SRAM RED XPLR E1, Quarq power meter, 40t

Bottom Bracket

SRAM DUB BSA 68 Wide

Wheels & Tires

Front Tire

Pathfinder 700x45, Tubeless Ready

Front Wheel

Roval Terra Aero CL, 27mm internal width, tubeless ready, 50mm depth, 21h, DT 350 hub, Centerlock disc, DT Swiss Competition spokes

Rear Tire

Pathfinder 700x45, Tubeless Ready

Rear Wheel

Roval Terra Aero CL, 27mm internal width, tubeless ready, 45mm depth, 24h, DT 350 hub, Centerlock disc, DT Swiss Competition spokes

Inner Tubes

700x32-50mm, 60mm Presta valve

Cockpit

Handlebars

Roval Terra Cockpit, Integrated Bar/Stem

Tape

Supacaz Super Sticky Kush

Saddle

Power Pro Mirror, Hollow Ti rails

SeatPost

S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset

Seat Binder

Integrated Wedge

Weight

Weight

7.7 kg (16 lb, 15.6 oz)

Weight Size

56

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
