Technical Specifications
Frameset
Frame
Specialized D'Aluisio Smartweld M5 Alloy, Hydroformed tubes, Progressive XC Geometry, 110mm travel, internal cable routing, BSA BB, 12x148mm spacing, 30.9mm Dropper post compatible
Seat Binder
Specialized Alloy, 34.9mm
Suspension
Fork
Fox 34 Performance Elite, Grip2 Damper, Compression adjust, 130mm travel, 44mm offset, 15x110mm
Rear Shock
Fox Float Performance, Evol LV, Ride Dynamics Tuned, 2-position compression adjust, 190x40mm
Brakes
Front Brake
SRAM G2 RS hydraulic disc, 4-Piston Caliper, 180mm rotor
Rear Brake
SRAM G2 RS hydraulic disc, 4-Piston Caliper, 180mm rotor
Drivetrain
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
Crankset
SRAM X1000 Eagle, DUB, 165/170/175mm
Rear Derailleur
SRAM GX Eagle, 12-speed
Shift Levers
SRAM GX, trigger, 12-speed
Cassette
SRAM PG-1230 Eagle 11-50t
Chain
SRAM SX Eagle, 12-speed
Chainrings
32t
Wheels & tires
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Spokes
DT Swiss Industry
Front Tire
Specialized Purgatory, GRID Casing, T9 Compound, 29x2.4
Rims
Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Rear Tire
Specialized Ground Control, GRID Casing, T7 Compound, 29x2.35
Inner Tubes
Standard 40mm PV 29x1.75-2.4
Cockpit
Stem
Alloy Stem, 35mm clamp, 60mm
SeatPost
X-Fusion Manic, 30.9, 125/150/170 Travel, 0mm offset
Handlebars
Specialized Alloy, 20mm rise, 35mm, 760mm wide
Grips
Specialized Trail Grips
Saddle
Body Geometry Power Comp, steel rails
Product details
Weight
13.53 kg (29 lb, 13.3 oz)
Weight Size
MD
Geometry
XS | S | M | L | XL |
|---|---|---|---|---|
| Crank Length | 165 | 170 | 170 | 175 |
| Handlebar Width | 760 | 760 | 760 | 760 |
| Stem Length | 60 | 60 | 60 | 60 |
| Saddle Width | 155 | 155 | 143 | 143 |
| Seatpost Length | 100 | 125 | 150 | 170 |
| Stack | 606 | 596 | 610 | 624 |
| Reach | 385 | 410 | 440 | 465 |
| Head Tube Length | 95 | 95 | 110 | 125 |
| Head Tube Angle (low) | 66 | 66 | 66 | 66 |
| Head Tube Angle (high) | 66.5 | 66.5 | 66.5 | 66.5 |
| BB Height (low) | 330 | 339 | 339 | 339 |
| BB Height (high) | 336 | 345 | 345 | 345 |
| BB Drop (low) | 42 | 33 | 33 | 33 |
| Trail | 117 | 117 | 117 | 117 |
| Fork Length, Full | 540 | 540 | 540 | 540 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 |
| Front Center | 685 | 709 | 745 | 776 |
| Chainstay Length | 437 | 437 | 437 | 437 |
| Wheelbase | 1119 | 1145 | 1181 | 1212 |
| Bike Standover Height | 762 | 783 | 783 | 792 |
| Seat Tube Length | 375 | 392 | 410 | 450 |
| Seat Tube Angle | 75 | 75 | 75 | 75 |
| Top Tube Length, Horizontal | 528 | 566 | 603 | 635 |
