Chisel Comp Shimano
Chisel Comp Shimano
SKU:93825-5101
1 in stock
Product Sold Out? Contact us and we will try to find it for you.
Read More
Read More
Tuned for victory!
The Chisel Comp is a light and very fast cross country bike with full suspension. It is 18.4% lighter than the nearest competitor and delivers noticeably fierce performance. Thanks to the advanced kinematics and geometry of the Epic 8 combined with the innovative
Features of the Specialized CHISEL COMP - 29" Mountain Bike - 2024
- D'Aluisio Smartweld frame with
FlipChip to adjust the geometry. -
RockShox SID Suspension fork with 120 mm travel and Rush damper cartridge. -
RockShox Deluxe Select+ Shock with Ride Dynamics Tune. - When things get dicey, the stroke of the lowerable TranzX seatpost can be infinitely adjusted without any problems thanks to the clever lever.
- Shimano SLX drivetrain with 1 × 12 gears.
- Hydraulic disc brakes with high braking power.
Details of the Specialized CHISEL COMP
"Speed Metal":
"Progressive Metalcore": The Chisel with 110 mm rear wheel travel in the Ride Dynamics Tune is related to the Epic 8, the Specialized racing machine for the World Cup. It shares performance features such as the advanced kinematics, the suspension with
"Power Metal": Thanks to the geometry and kinematics of the World Cup-winning Epic 8, the Chisel surprises with incredible pedaling efficiency. This makes it the most efficient full-suspension XC bike made of aluminum. The steep seat angle positions the rider centrally in the bike for optimum power transfer and the perfected
"Groove Metal": Flexible struts have been added to the Chisel for maximum suspension performance. This and the
No "heavy metal": The Chisel shines with a hydroformed seat tube that integrates the pivot point of the rocker, the main pivot and, absolutely innovative, the bottom bracket shell. In this way, Specialized saves additional material and weight compared to a traditional bike, where the pivot points and bottom bracket shell are welded onto the seat tube.
Share
Technical Specifications
Frameset
Frame
Specialized D'Aluisio Smartweld M5 Alloy, Hydroformed tubes, Progressive XC Geometry, 110mm travel, internal cable routing, BSA BB, 12x148mm spacing, 30.9mm Dropper post compatible
Seat Binder
Specialized Alloy, 34.9mm
Suspension
Rear Shock
RockShox Deluxe Select+, Ride Dynamics Tuned, Two Position, Rebound Adjust, 190x40mm
Fork
RockShox SID, Rush damper, 44mm offset, 15x110mm thru-axle, 120mm of travel, Maxle Stealth
Cockpit
Saddle
Body Geometry Power Sport, steel rails
SeatPost
TranzX Dropper post, 30.9mm, XS-SM: 100mm, M: 125mm, L-XL: 150mm
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Grips
Specialized Trail Grips
Handlebars
Specialized Alloy, 20mm rise, 31.8mm, 760mm wide
Brakes
Front Brake
Shimano M6100, 2-piston caliper, hydraulic disc, 180mm rotor
Rear Brake
Shimano M6100, 2-piston caliper, hydraulic disc, 160mm rotor
Drivetrain
Shift Levers
Shimano SLX, M7100, 12spd
Cassette
Shimano Deore M6100, 12spd w/Hyperglide+, 10-51t
Rear Derailleur
Shimano SLX M7100, SGS, 12-speed
Chain
Shimano Deore M6100, 12spd w/quick link
Crankset
Shimano MT-511, 32t chainring
Chainrings
32t
Bottom Bracket
Shimano BB-MT501 BSA
Wheels & Tires
Rims
Specialized Alloy, Tubeless ready, 27mm inner width, disc, 28h
Front Hub
Shimano MT410-B, Centerlock 28h, 15x110 Boost
Rear Hub
Shimano MT410-B, Centerlock 28h, 12x148 Boost, Microspline
Front Tire
Specialized Ground Control, Control Casing, T5 Compound, 29x2.35
Rear Tire
Specialized Fast Trak, Control Casing, T5 Compound, 29x2.35
Spokes
Stainless, 14g
Inner Tubes
Standard 40mm PV 29x1.75-2.4
Weight
Weight
12.86kg (28 lb, 5.6 oz)
Weight Size
MD
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
XS | S | M | L | XL |
---|---|---|---|---|
Crank Length | 165mmm | 170mm | 170mm | 175mm |
Handlebar Width | 760mm | 760mm | 760mm | 760mm |
Stem Length | 60mm | 60mm | 60mm | 60mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm |
Seatpost Length | 357mm | 412mm | 412mm | 459mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
Stack | 602.3mm | 593mm | 606mm | 620mm |
Front Center | 682mm | 706mm | 742mm | 773mm |
Reach | 390mm | 415mm | 445mm | 470mm |
Chainstay Length | 437mm | 437mm | 437mm | 437mm |
Head Tube Length | 95mm | 95mm | 110mm | 125mm |
Head Tube Angle (low) | 66.5° | 66.5° | 66.5° | 66.5° |
Wheelbase | 1115mm | 1141mm | 1177mm | 1208mm |
Bike Standover Height | 756mm | 777mm | 777mm | 787mm |
BB Height (low) | 326mm | 336mm | 336mm | 336mm |
Seat Tube Length | 375mm | 392mm | 410mm | 450mm |
BB Height (high) | 332mm | 342mm | 342mm | 342mm |
Seat Tube Angle | 75.5° | 75.5° | 75.5° | 75.5° |
BB Drop (low) | 46mm | 36mm | 36mm | 36mm |
Top Tube Length, Horizontal | 527mm | 565mm | 602mm | 634mm |
Trail | 113mm | 113mm | 113mm | 113mm |
Fork Length, Full | 530mm | 530mm | 530mm | 530mm |
