Technical Specifications
Frameset
Frame
Specialized E5 Premium Aluminum, flat mount disc, rack and fender eyelets, fully manipulated tubing w/ SmoothWelds, internal cable routing, threaded BB, 12x142mm thru-axle
Cockpit
Tape
Specialized S-Wrap
Stem
3D-forged alloy, 31.8mm, 7-degree rise
Handlebars
Specialized Shallow Drop, 70x125mm, 31.8mm clamp
Saddle
Body Geometry Bridge Saddle, steel rails
SeatPost
Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Seat Binder
Bolt-type, Rack Compatable 31.8mm
Suspension
Fork
Specialized FACT full carbon, flat mount disc, 1-1/8" to 1-3/8" taper, fender eyelets, 12x100mm thru-axle
Brakes
Front Brake
Tektro MD-550 Mechanical Disc - 160mm rotor
Rear Brake
Tektro MD-550 Mechanical Disc - 160mm rotor
Drivetrain
Shift Levers
Shimano Claris 2000, 8-speed
Front Derailleur
Shimano Claris, 8-speed, braze-on
Rear Derailleur
Shimano Claris, 8-speed
Cassette
SunRace, 8-speed, 11-32t
Chain
KMC X8 w/ Missing Link™
Crankset
Shimano Claris R200 - 50/34t
Chainrings
50/34T
Bottom Bracket
Shimano 68mm threaded
Wheels & Tires
Front Wheel
Axis Sport Disc
Rear Wheel
Axis Sport Disc
Front Tire
Specialized Roadsport, 700X30c
Rear Tire
Specialized Roadsport, 700X30c
Inner Tubes
700x28-32, 48mm Presta Valve
Product Details
Product ID
221796
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
44 | 49 | 52 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Crank Length | 165mm | 165mm | 170mm | 170mm | 175mm | 175mm |
| Handlebar Width | 360mm | 380mm | 400mm | 420mm | 420mm | 440mm |
| Stem Length | 70mm | 80mm | 90mm | 100mm | 100mm | 110mm |
| Saddle Width | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm |
| Seatpost Length | 300mm | 300mm | 350mm | 350mm | 350mm | 350mm |
| Seat Tube Angle | 75.25° | 75.25° | 73.25° | 73.25° | 73.25° | 73.25° |
| Stack | 519mm | 536mm | 552mm | 569mm | 590mm | 610mm |
| Head Tube Length | 110mm | 125mm | 140mm | 155mm | 175mm | 195mm |
| BB Height | 273mm | 273mm | 273mm | 274mm | 274mm | 275.5mm |
| BB Drop | 77mm | 77mm | 77mm | 76mm | 76mm | 74.5mm |
| Reach | 356mm | 359mm | 364mm | 370mm | 378mm | 386mm |
| Trail | 81mm | 74mm | 71mm | 64mm | 61mm | 58mm |
| Wheelbase | 984mm | 984mm | 995mm | 998mm | 1008mm | 1017mm |
| Front Center | 576mm | 577mm | 583mm | 585mm | 594mm | 603mm |
| Fork Length, Full | 378mm | 378mm | 378mm | 378mm | 378mm | 378mm |
| Head Tube Angle | 69.5° | 70.5° | 71° | 72° | 72.5° | 73° |
| Top Tube Length, Horizontal | 493mm | 500mm | 530mm | 541mm | 556mm | 569mm |
| Bike Standover Height | 715mm | 739mm | 761mm | 781mm | 801mm | 821mm |
| Fork Rake/Offset | 47mm | 47mm | 47mm | 47mm | 47mm | 47mm |
| Chainstay Length | 420mm | 420mm | 425mm | 425mm | 425mm | 425mm |
| Seat Tube Length | 430mm | 460mm | 490mm | 510mm | 530mm | 550mm |
