Technical Specifications
Frameset
Frame
Aethos FACT 10R Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc
Suspension
Fork
FACT Carbon, 12x100mm thru-axle, flat-mount disc
Cockpit
Handlebars
Specialized Expert Shallow Drop, alloy, 125mm drop x 75mm reach
Saddle
Body Geometry Power Expert
Stem
Specialized Pro SL, alloy, 4-bolt
Tape
Supacaz Super Sticky Kush
SeatPost
Roval Alpinist Carbon Seatpost
Seat Binder
Specialized Alloy, 30mm
Brakes
Rear Brake
SRAM Rival eTAP AXS, hydraulic disc
Front Brake
SRAM Rival eTAP AXS, hydraulic disc
Drivetrain
Shift Levers
SRAM Rival eTap AXS
Front Derailleur
SRAM Rival eTAP AXS, braze-on
Rear Derailleur
SRAM Rival eTap AXS, 12-speed
Cassette
SRAM Rival, 12-speed, 10-36t
Crankset
SRAM Rival AXS Power Meter
Chainrings
48/35T
Bottom Bracket
SRAM DUB BSA 68
Chain
SRAM Rival 12-speed
Wheels & Tires
Front Wheel
Roval C38, 21mm internal width carbon rim
Rear Wheel
Roval C38, 21mm internal width carbon rim
Front Tire
S-Works Turbo, 120 TPI, folding bead, BlackBelt protection, 700x28mm
Rear Tire
S-Works Turbo, 120 TPI, folding bead, BlackBelt protection, 700x28mm
Inner Tubes
700x20-28, 48mm Presta Valve
Weight
Weight
7.64kg (16 lb, 13.5 oz)
Weight Size
56
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
49 | 52 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|
Crank Length | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
Handlebar Width | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
Stem Length | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 300mm | 300mm | 360mm | 360mm | 360mm | 360mm |
Wheelbase | 973mm | 975mm | 978mm | 991mm | 1005mm | 1012mm |
Top Tube Length, Horizontal | 508mm | 531mm | 540mm | 562mm | 577mm | 595mm |
Bike Standover Height | 705mm | 728mm | 748mm | 769mm | 796mm | 824mm |
Seat Tube Length | 431mm | 462mm | 481mm | 504mm | 532mm | 567mm |
Seat Tube Angle | 75.5° | 74° | 74° | 73.5° | 73.5° | 73° |
Stack | 514mm | 527mm | 544mm | 565mm | 591mm | 612mm |
Reach | 375mm | 380mm | 384mm | 395mm | 402mm | 408mm |
Head Tube Length | 109mm | 120mm | 137mm | 157mm | 184mm | 204mm |
Head Tube Angle | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 74° |
BB Height | 266mm | 266mm | 268mm | 268mm | 268mm | 268mm |
BB Drop | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm |
Trail | 63mm | 58mm | 58mm | 55mm | 55mm | 52mm |
Fork Length, Full | 369mm | 369mm | 369mm | 369mm | 369mm | 369mm |
Fork Rake/Offset | 47mm | 47mm | 44mm | 44mm | 44mm | 44mm |
Front Center | 574mm | 577mm | 579mm | 591mm | 606mm | 613mm |
Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
